Advantech 160-250S00-000 REMOTE M & C PANEL

Synthesized Frequency Up-Converters from FCS301 series are packaged in a compact standard 1RU enclosure. Their built-in instrumentation detector associated with discrete power thresholds alarms allows evolved system monitoring configurations. The straightforward front panel operation, and RS232 terminal mode enables quick on-site setup Offered remote management interfaces ensure complete flexibility of integration into existing or new installations. The user-friendly front panel or the RS485 remote interface will provide full set-up and fault monitoring facilities Ethernet option will allow the operator to pilot system operation either through SNMP or Web based interface. Delivered spectral purity, low phase noise and stability exceed the requirements of all major international satellite network operators. The system reference guaranteeing conversion function’s accuracy can optionally be provided externally, internally as a highly stable temperature compensated oscillator, or with auto-detection capacity that will use internal reference only in the absence of an externally provided one.’

• Built-in instrumentation RMS output detector
• Adjustable output power threshold alarms
• Outperforms IESS 308/309 phase noise by 3dB
• Superior linearity
• 125 kHz step size
• 40dB attenuation control range
• On-site reference aging correction capability
• Intuitive front panel user interface
• RS232 terminal and RS485 packet mode remote interface
• 10 operating gain and frequency
